Handbook of microwave engineering (Gentili Gian Guido;Oldoni Matteo - Maggioli)

di Gentili Gian Guido Oldoni Matteo
ISBN/EAN
9788891675385
Editore
Maggioli Editore
Collana
Politecnica
Formato
Libro in brossura
Anno
2025
Pagine
134

Disponibile

18,00 €

This book offers a synthetic presentation of the fascinating subject of microwave engineering technology, intended for a university master’s degree course. The topics are: a quick review of guided wave propagation, matrix description of circuits, microwave passive devices, resonators and finally microwave filters, a subject that covers about half of the book. The final goal is to smoothly drive the reader towards an educated design of the devices discussed in the book. Because of the rather practical and synthetic approach, we assume some background on electromagnetic waves and distributed circuits.

Gian Guido Gentili
graduated from Politecnico di Milano and in 1989 he joined the CNR (National Research Council), first as a junior researcher, then as a senior researcher. Since 2002 he is an associate professor at Politecnico di Milano. His main research interests are microwave passive devices, antennas and computational electromagnetics. He is a member of IEEE and has published about 150 papers in international journals and international and national conferences. He contributed to the Encyclopedia of RF and Microwave Engineering with two chapters, one on horn antennas and another on Ortho-ModeTransducers. He published several educational books and exercise books on electromagnetics.

Matteo Oldoni
received his Ph.D. degree in Information Technology from the Politecnico di Milano, Milan, Italy, in 2013. Mr. Oldoni was the recipient of the Young Engineers Prize of the 39th European Microwave Conference. He has worked as Microwave Designer in the Passive Microwave Components Laboratory of a private company, becoming a Member of the Technical Staff, and cooperated with several companies and research institutions internationally. From June 2022 he is a full-time researcher at the Electronics, Information and Bioengineering Dept. of Politecnico di Milano. His research interests include synthesis and design techniques for microwave filters, algorithm development for computer-aided tuning, and antenna design. He is an Associate Editor of IEEE Microwave and Wireless Technology Letters since 2023.

Maggiori Informazioni

Autore Gentili Gian Guido;Oldoni Matteo
Editore Maggioli Editore
Anno 2025
Tipologia Libro
Collana Politecnica
Lingua Inglese
Indice

1 Transmission lines and waveguides
1.1 Introduction
1.2 Modal propagation
1.3 TEM lines
1.3.1 The coaxial cable
1.3.2 The stripline
1.4 Quasi-TEM lines
1.4.1 The microstrip line
1.4.2 The coplanar line
1.4.3 The slotline
1.5 TE/TM waveguides
1.5.1 The rectangular waveguide
1.5.2 The circular waveguide
1.6 Hybrid modes
1.7 Coupled lines

2 Matrix description of circuits
2.1 Introduction
2.2 The concept of impedance and admittance
2.3 Impedance and admittance matrix
2.4 The scattering matrix
2.5 Two-port circuits
2.5.1 Impedance and admittance matrix
2.5.2 Scattering matrix
2.5.3 ABCD matrix

3 Microwave passive devices
3.1 Coupled lines coupler
3.2 The Wilkinson divider
3.3 The 90◦ 3 dB hybrid coupler
3.4 The 180â—¦ 3 dB coupler
3.5 The magic Tee
3.6 The Gysel coupler
3.7 The circulator

4 Microwave resonators
4.1 Introduction
4.2 The Q-factor
4.3 Q-factor and 3-dB bandwidth
4.4 Transmission line resonators
4.4.1 Short-circuited line
4.4.2 Open-circuited line
4.5 Quality factor of transmission line resonators
4.6 Cavity resonators
4.7 The rectangular cavity
4.8 The cylindrical cavity

5 Microwave filters
5.1 Introduction
5.2 Scattering parameters
5.3 The filter specifications
5.4 Identification of the polynomial in the normalized lowpass domain
5.4.1 The normalized angular frequency domain
5.4.2 The Chebyshev low-pass polynomial
5.5 The low-pass prototype
5.6 Impedance scaling
5.7 Frequency transformations
5.7.1 Define the low-pass cutoff frequency
5.7.2 Design a high-pass filter
5.7.3 Design a band-pass filter
5.7.4 Design a band-stop filter
5.8 Microwave implementation
5.8.1 Richard’s transformations
5.8.2 Kuroda identities
5.9 Inverters
5.10 Normalized design
5.11 Band-pass filter design with inverters
5.11.1 Impedance scaling with inverters
5.12 Band-stop filter design with inverters
5.13 Microwave implementation of band-pass filters
5.13.1 Inverter implementation
5.13.2 Resonator implementation
5.14 Band-pass design equations with physical resonators
5.15 Filter topologies
5.15.1 Bandpass filters with λ/4 resonators and λ/4 inverters
5.16 Microstrip/stripline implementation
5.16.1 End-coupled band-pass filters
5.16.2 Edge-coupled band-pass filters
5.16.3 Rectangular waveguide band-pass filters
5.17 Filter with general cavity resonators
5.17.1 The coupling coefficient
5.17.2 Input/output coupling
5.18 A design example
5.19 Losses in microwave filters
5.19.1 Effect of losses

A Modes in the rectangular waveguide
A.1 TE modes
A.1.1 TM modes
A.2 Table of standard waveguides
Larghezza 0
Stato editoriale In Commercio
